    Product Name : Push-Pull Solenoid
    Product No : RG-T-1421SL
    Inquiry
    Product Introduction



    ▪ Plunger Weight:3g

    ▪ Total Weight: 18g

    ▪ COIL DATA

    Duty cycle(%)= X 100%Continuous (100%)Or less(50%)Or less(25%)Or less(10%)
    MAX. "on" time in seconds 100 36 7
    Watts at 20°C 1.8 3.6 7.2 18
    Ampere-turns at 20°C 236 334 472 746
    Type no.Resistance (20°C) ¡Ó10%No. turnsVolts DC
    RG-T-1421SL06AA 5 415 3 4.2 6 9.5
    RG-T-1421SL12AA 20 800 6 8.5 12 19
    RG-T-1421SL24AA 80 1600 12 17 24 38
    RG-T-1421SL48A 320 3130 24 34 48 76
